Programming manual.

CNC 8070

PATH CONTROL.

Circular interpolation (G02/G03).

·162·

(REF: 1709)

Properties of the function and Influence of the reset, turning the

CNC off and of the M30 function.

• Functions G264 and G265 are modal and incompatible with each other.

• On power-up, after executing an M02 or M30, and after an emergency or reset, the CNC

assumes function G265.
