Programming manual.

CNC 8070

·25·

(REF: 1709)

Symbols that the product may carry.

Ground symbol.

This symbol indicates that that point must be under voltage.

ESD components.

This symbol identifies the cards as ESD components (sensitive to electrostatic discharges).
