Programming manual.

CNC 8070

TOOL COMPENSATION

13.

Tool length compensation

·261·

(REF: 1709)

• To activate this compensation, program "D<n>", where <n> is the tool offset number that

contains the tool dimensions that will be used as compensation values.

• To cancel this compensation, program "D0".

Once one of these codes has been executed, tool length compensation will be activated or

cancel during the next movement of the longitudinal axis.
