Programming manual.

CNC 8070

17.

ANGULAR TRANSFORMATION OF AN INCLINE AXIS.

·306·

(REF: 1709)

Considerations for the angular transformation of an incline

axis.

The axes that make up the angular transformation must meet the following requirements:

• Both axes must belong to the same channel.

• Both axes must be linear.

• Both axes may be masters in a pair of slaved (coupled) axes or gantry axes.

Home search is not possible when the angular transformation is active.

If the angular transformation is active, the coordinates displayed will be those of the

Cartesian system. Otherwise, it will display the coordinates of the real axes.
