Programming manual.

CNC 8070

HSC. HIGH SPEED MACHINING.

20.

HSC SURFACE mode. Optimization of surface finish.

·369·

(REF: 1709)

When changing HSC modes, the CNC assumes the default values set in the machine

parameters.

Execute an HSC mode starting with initial conditions.

To execute in HSC mode starting with initial conditions, first cancel the previous mode. See

"20.6 Canceling the HSC mode." on page 374.

Example 2.

#HSC ON [CONTERROR, E0.050]

#HSC OFF

#HSC ON [SURFACE]

(Chordal error = machine parameter HSCROUND)
