Programming manual.

CNC 8070

STATEMENTS AND INSTRUCTIONS

22.

Programming statements

·391·

(REF: 1709)

Example. Convert parameters. Program after ISO generation.

$FOR P1=0,240,120

G73 Q[P1]

$ENDFOR

G73 Q[0]

G73

G73 Q[120]

G73

G73 Q[240]

G73
