Programming manual.

CNC 8070

COORDINATE SYSTEM

Coordinate programming

·71·

(REF: 1709)

Programming example (·T· model)

G00 G90 X0 Z160 ; Point P0

G01 X30 Q90 ; Point P1

G01 Z110 Q150 ; Point P2

G01 Z80 Q180 ; Point P3

G01 Z50 Q145 ; Point P4

G01 X100 Q90 ; Point P5
