FORESIGHT TIMS MVP - Example

IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
TIMS MVP™ Setup and Configuration Guide 119
Example
This first example shows a video image with the correct values for Left/Right Framing.
Notice that both edges of the video image align against the edge; there is no distortion
or clipping.
Figure 28: Example of proper video image framing
