IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
126 TIMS MVP™ Setup and Configuration Guide
Examples
In this example, the video image is too large and extends beyond the top edge.
Figure 34: Example of video image that is clipped at the top edge
To adjust the image, decrease the VBP to move the image down. This will align the
video image to the top edge.
