IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
TIMS MVP™ Setup and Configuration Guide 127
In the next example, the video image is too small. The top edge is clipped and the
bottom edge is above the bottom edge of the image.
Figure 35: Example of video image that is clipped at the top edge and is not aligned with the bottom edge
To adjust the image, increase the VBP to increase the size of the image. This will align
the video image to the top edge.
