IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
146 TIMS MVP™ Setup and Configuration Guide
Changing the Miscellaneous Settings
Use the Miscellaneous tab to edit the following video settings:
Figure 51: Miscellaneous Settings
Specifies the type of sync information that is
available during the vertical sync and vertical front porch
periods.
Specifies the order of the signal fields.
Old method of scaling. No longer supported.
Specifies an absolute width reserved for one line of
video in frame grabber (i.e. video board) memory.)
Used only in the accustream170 series frame grabbers.
Not supported in the AS170+, 205a, HD+ and HD+C
series frame grabbers.
