Get Connected
8 TIMS MVP™ Setup and Configuration Guide
Use the following table for guidance.
Non-NTSC/PAL
Video Source
Connector
RGB
3 Wire
4 Wire
5 Wire
or
Monochrome
Sync
Composite
Horizontal
Vertical
DVI to 5-BNC Cable 030093,
Male or
DVI to BNC adapter, 030175
DVI to 5-BNC Cable 030093,
Male
NTSC/PAL
S-Video
S-Video Cable, Standard 4-Pin
DIN, Male, 030102
Composite Color Video
S-Video to BNC adapter,
030193
S-Video to RCA, 030194
