Get Connected
10 TIMS MVP™ Setup and Configuration Guide

Trigger Adaptor
Male Phono Adaptor (P/N: 030123)

DVI-In – RGB or
Monochrome
DVI-D to VGA cable (optional)
or
DVI to BNC Cable (P/N: 030193)
or
DVI to BNC Adaptor (P/N: 030175)

HDMI In – NTSC or PAL
DVI-D to HDMI cable (optional)
or
HDMI to HDMI cable (optional)

Y/C In – NTSC or PAL
S-video to S-video cable (P/N: 030102)
or
for composite color: an S-video to composite
color adaptor (optional)

Optional composite video
cable
BNC to S-video adaptor (P/N: 030193)
