The DMS Go+ 1 Introduction
DMS Go+ Edition 4 (05/2014) 1-13
● high memory capacity with 2GB SD card. SD cards
with a memory capacity up to 16
GB can be used.
● measuring range 0.25 … 14000 mm (steel), depend-
ing on the probe, material, and surface
● digital resolution 0.01 mm or 0.1 mm (selectable)
over the entire measuring range
● units selectable between inch and mm
● integrated data recorder for 100,000 measurements
per file. Several files can be saved to the SD card.
● up to 16 user-definable comments for every file for-
mat with up to 16 alphanumeric characters per mea-
suring point
● automatic probe detection with dialog probes, opti-
mized setup and power of the instrument, especially
higher measuring accuracy thanks to the individual V-
path correction data stored in the corresponding
probe used
● MicroGrid function for testing the direct surroundings
of the measuring point
● single-element operating mode with measurement at
echo flank or echo peak
● MIN operating mode with increased pulse repetition
frequency for detecting the smallest reading in a se
-
ries of measurements
● Dual-Multi operating mode for measuring through
coatings
● adjustable minimum and maximum limits with alarm
signaling through color change of the reading
● locking function to prevent unintentional changes to
the adjustment values
