13-9 SECURENET AUDIO/MODULATION
CONTROL
The Audio Zone located at the lower right of the
screen (figure 13-13) is used to control the
multi-purpose audio synthesizer section of the
R2670. Signals generated by the audio
synthesizer are coupled internally to the generator
modulation input as well as to the MOD OUT
connector on front panel. The main categories of
modulation in SECURENET mode are Voice and
Bit Error Rate (BER). Many of the features
available in standard mode are not available in
SECURENET mode. The Audio Zone has been
changed accordingly to simplify testing of
SECURENET radios and equipment.
Each modulation signal has a cursor field for
entering its desired level. Use the keypad or
TUNING knob to enter the desired level.
An additional cursor field, adjacent to each level
entry, is used to switch each selection on and off
using softkeys. This field is located at the
extreme right side of the zone. There are three
possible conditions for this softkey selection.
CONT activates continuous ON condition, or
continuous cycling if a sequence has been
selected. A "~" symbol is indicated at the
extreme right, adjacent to the level to indicate
continuous ON.
OFF switches off the modulation source. Off is
indicated by an "X" at the extreme right,
adjacent to the level.
13-9.1 Modulation Sources
There are two m
odulation sources selectable in
the Audio Zone, Fixed 1 kHz and External.
13-9.1.1 Fixed 1 kHz
The analyzer produces a fixed 1 kHz m
odulation
source, which can be selected independently from
the other audio synthesizers. Level control and
on-off selection is previously described.
13-9.1.2 External
External modulation can be applied to the
external modulation input (EXT MOD IN)
connector on the front panel. When external
modulation source is selected, this external
modulation input is summ
ed with the microphone
(voice) input. Level control and on-off selection
for an external modulation source are selectable
via softkey or the TUNING knob.
13-9.2 Voice Encode
The Audio Zone provides controls for both signal
level and frequency deviation of Voice baseband
signal that is used to m
odulate the SECURENET
RF transmissions.
13-9.2.1 Monitor Mode
The analyzer can generate SECURENET voice
patterns when placed in the Monitor mode. The
SECURENET signal is encrypted with one of the
hardware algorithms.
Be sure Monitor is selected in the RF Control
Zone in the upper right section of display. Move
cursor to the Audio Zone and place the cursor in
the "Code:" field. Select Voice modulation using
the VOICE softkey. Selection of Monitor Voice
allows for the addition of the following audio
sources:
External + microphone, or
1 kHz tone
These inputs are selected by using the off and
continuous switches and the level is adjusted
using the keypad or tuning knob. The level range
varies depending on whether the bandwidth (in
the RF Zone) is set to narrow or wide.
BW Setting Audio level Range
Narrow 0.000 to 0.795 volt maximum,
in 0.001 volt increments
Wide 0.00 to 7.95 volt maximum, in
0.01 volt increments
180
