Section 4
APPLICATIONS
4-1 BASIC FM TRANSMITTE TESTING
This section of the manual contains information
on typical test setups to perform some of the
more common radio tests using R2600 Series
Communications System Analyzers.
General Dynamics takes no responsibility for
application accuracy, applicability, or safety.
Always refer to your own transceiver's service
manual for recommended test methods and spec-
ifications
IN/OUT
GEN
OUT
VERT/SINAD
DIST/DVM
COUNTER IN
DEMOD
OUT
MOD
OUT
EXT
MOD
IN
1V
PK
REF
MIC
TRANSMITTER UNDER TEST
RF OUTPUT
MIC
AUDIO
IN
ANT
ANTENNA
TEKA24A
RF LOAD
ANTENNA
OR
Figure 4-1. Basic FM Transmitter Testing Setup
64
