1-3.4 Replacement Fuses
For continuous protection against risk of fire,
replace only with a fuse of the same type and
rating. Part numbers for replacement fuses are
shown in Tables 1 and 2.
Other fuses are located inside the Analyzer and
should be replaced by Factory Authorized
Service Personnel or other qualified maintenance
personnel.
Table 1. Operator Replaceable Fuses
LOCATION
OPERATION
FUSE RATING
VOLTS AMPS
FUSE
TYPE
PART NUMBER
Rear Panel 115/230 VAC L 250V 2.5A F 65-P30222C003
* Rear Panel 115/230 VAC N 250V 2.5A F 65-P30222C003
Front Panel ANT 125V 1/16A F 65-P30277C002
Front Panel GEN 125V 1/16A F 65-P30277C002
Table 2. Internal Fuses
LOCATION
OPERATION
FUSE RATING
VOLTS AMPS
FUSE
TYPE
PART NUMBER
* Inside Rear
Panel
12 VDC 250V 10A F F03A250V10A
Power Supply 115/230 VAC N 250V 1/4A F 65-P30308C001
Battery Pack 115/230 VAC L 250V 0.5A F 65-P30222C002
* Battery Pack 115/230 VAC N 250V 0.5A F 65-P30222C002
Battery Pack 12 VDC 250V 15A F 65-P26348A004
*Note: For Analyzers with one AC fuse
(F02A250V3A) and one DC fuse (F03A250V10A)
on the rear panel, the neutral fuse (N) does not
exist.
