Section 9
ASTRO TRUNKING OPERATING INSTRUCTIONS
CAUTION
When testing a radio, the analyzer generates a control channel signal. Take care to prevent this
signal from unintentionally capturing other radios in the area. Observe the following precautions:
Do not use an antenna on the analyzer for over-the-air testing.
Use double-shielded cables on the analyzer to carry signals to and from the radio.
Locate the analyzer at least 35 feet from the antenna of a unit that is working in the same system
that the analyzer is testing.
9-1 INTRODUCTION
The R2670 Digital Communications System
Analyzer includes all the features of the R2600
Series Communications System Analyzer. Refer
to sections 8, 9, and 10 of the General Operation
section of this manual for general installation in-
formation, a description of the control functions,
and general operational information. The
following sections of this manual contain
information on how to connect trunked radios
under test to the analyzer and how to set controls
and indicators to obtain the correct screen
display.
Error/Warning Messages
Refer to Appendix G for a listing and descrip-
tion of setup and radio error messages. Mes-
sages common to all the R2600 Series equip-
ment are detailed in paragraph 9-4 of the
General Operation section of this manual.
9-2 TEST SETUP
9-2.1 Connecting a Radio
Use a 50 ohm BNC cable and an N to BNC
adapter to connect from the RF I/O port of the
trunking analyzer to the antenna port of the radio
as shown in figure 9-1.
CAUTION
Observe the input power ratings and
warnings of the analyzer to insure that no
damage occurs to the analyzer.
135
