Figure 2-2. Side, Rear, and Bottom Panels

RS-232 PORT

10 MHZ REFERENCE

OSCILLATOR IN/OUT

DC INPUT PW

R

CONNECTOR

A

C PLUG

FUSES

INTERNAL/EXTERNAL

REFERENCE OSCILLATOR

SWITCH

REFERENCE OSCILLATOR

CALIBRATION ADJUST

LINE VOLTAGE

SELECTOR SWITCH

VGA PORT

(

BOTTOM SIDE

)
