General Dynamics R2600 Series User Manual

Table 7-15. Trunk II Signaling Events
System Initiated Phone Interconnect Testing Without Auto Affiliation
SIGNALING EVENT DESCRIPTION
F Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel
to lock the radio.
G Transpond OSW Sent The trunking analyzer sent the Transpond OSW to the radio.
H Transpond OSW Received The trunking analyzer detected the Transpond ISW from the radio.
I Ring OSW Sent The trunking analyzer sent the Ring OSW to the radio.
J ISW Received
The radio sent an Inbound Signaling Word (ISW) on the control channel to
indicate the radio has been keyed.
Q Channel Grant OSW Sent
The trunking analyzer sends channel grant OWSs on the control channel.
Channel grants direct the radio to the voice channel to use.
U LS Word Sent On VC The trunking analyzer sends a low-speed data word on the voice channel.
V Connect Tone Received On VC The trunking analyzer decoded the connect tone sent by the radio.
Y Hangup Received The trunking analyzer decoded the Hangup ISW from the radio.
Table 7-16. Trunk II Signaling Events
System Initiated Phone Interconnect Testing With Auto Affiliation
SIGNALING EVENT DESCRIPTION
A Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel
for the radio to lock onto.
D Affiliate ISW Received The trunking analyzer received the Affiliate ISW from the radio.
E Affiliate OSW Sent
The trunking analyzer sends Affiliate OSWs on the control channel. The
Affiliate OSW acknowledges the radio is registered on the system and tells
the radio which connect tone to use.
F Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel to
lock the radio.
G Transpond OSW Sent The trunking analyzer sent the Transpond OSW to the radio.
H Transpond OSW Received The trunking analyzer detected the Transpond ISW from the radio.
I Ring OSW Sent The trunking analyzer sent the Ring OSW to the radio.
J ISW Received
The radio sent an Inbound Signaling Word (ISW) on the control channel
indicating the radio has been keyed.
Q Channel Grant OSW Sent
The trunking analyzer sends channel grant OWSs on the control channel.
Channel grants direct the radio to the voice channel to use.
U LS Word Sent On VC The trunking analyzer sends a low-speed data word on the voice channel.
V Connect Tone Received On VC The trunking analyzer decoded the connect tone sent by the radio.
Y Hangup Received The trunking analyzer decoded the Hangup ISW from the radio.
124
