NOTE
If SMARTZONE auto affiliation has been
selected, the operator is prompted to apply
power to the radio. Once the test radio is
turned on, it begins to search for a control
channel. When the radio finds the control
channel, it performs an auto registration
sequence with the analyzer, and the
registration data is displayed.
7. The status thermometer displays the major
signaling events that occur during a radio
initiated Call Alert test. Refer to table 10-5
(Astro auto affiliation disabled), or table 10-6
(Astro with auto affiliation).
The trunking analyzer generates an idle
pattern on the control channel and prompts the
operator to key the transmitter. When the
radio sends an ISW, the analyzer decodes it
and displays it.
If the ISW call type is a call alert, the analyzer
waits a short period of time and sends an
acknowledgment to the radio that the call alert
was received, and terminates the test. During
the execution of the test sequence, the status
thermometer is appropriately updated.
8. Press the
stop test softkey to terminate testing.
Table 10-5. Astro Signaling Events Radio Initiated Call Alert Testing Without Auto Affiliation
SIGNALING EVENT DESCRIPTION
F Control Channel Idle The trunking analyzer outputs a background pattern on the control channel
to lock the radio.
L Dual ISW Received The trunking analyzer received a dual word ISW from the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
O Call Alert Ring Ack OSW The trunking analyzer sends call alert ring acknowledge OSW to simulate
the system sending an acknowledge to the requesting radio.
Table 10-6. Astro Signaling Events Radio Initiated Call Alert Testing With Auto Affiliation
SIGNALING EVENT DESCRIPTION
A Control Channel Idle The trunking analyzer outputs a background pattern on the control channel
for the radio to lock onto.
D Affiliate ISW Received The trunking analyzer received the Affiliate ISW from the radio.
E Affiliate OSW Sent The trunking analyzer sends Affiliate OSWs on the control channel. The
Affiliate OSW acknowledges the radio is registered on the system and tells
the radio which connect tone to use.
F Control Channel Idle The trunking analyzer outputs a background pattern on the control channel
to lock the radio.
L Dual ISW Received The trunking analyzer received a dual word ISW from the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
O Call Alert Ring Ack OSW The trunking analyzer sends call alert ring acknowledge OSW to simulate
the system sending an acknowledge to the requesting radio.
152
