Be sure GENERATE is selected in the RF Zone
in the upper right section of display. Move cursor
to the Audio Zone and place the cursor in the
"Code:" field. Select Voice modulation using the
VOICE FRAME softkey.
When code VOICE FRAME is selected in the
Audio Zone (Figure 21-14), the analyzer allows
audio inputs to the modulator to be selected from
two sources:
External + microphone, or
1 kHz tone.
Controls for each modulating input consist of a
switch with values of Off and Continuous. Move
cursor to the appropriate switch field and turn the
modulating input on "~" or off "X" using the
softkeys.
The audio inputs also include a level control for
precisely setting the audio input to the modulator.
Use the keypad or TUNING knob to enter the de-
sired level. The level range varies depending on
whether the bandwidth (in the RF Zone) is set to
narrow or wide.
BW Setting Audio Level Range
Narrow 0.00 to 9.95 kHz maximum,
in 0.01 kHz increments
Wide 00.0 to 99.5 kHz maximum,
in 0.1 kHz increments
In Generate mode, deviation control is available
in the Audio Zone consisting of a switch with
values of Off and Continuous, and a level control.
Move cursor to the switch field and turn
deviation on "~" or off "X" using the softkeys.
Use the keypad or TUNING knob to enter the de-
sired deviation. The deviation range varies
depending on whether the bandwidth (in the RF
Zone) is set to narrow or wide.
BW Setting Deviation Range
Narrow 0.00 to 5.00 kHz maximum, in
0.01 kHz increments
Wide 00.0 to 50.0 kHz maximum, in
0.10 kHz increments
The default deviation setting for Project 25 is
2.83 kHz.
21-9.2.3 Voice Frame Embedded Signaling
(Generate)
When the audio source is selected to Voice
Frame, a display table user selection is available
which provides access to the embedded signaling
information contained in voice frames. The
display table presentation is shown in
Figure 21-14. The following information is
encoded by the Project 25:
Embedded Information Size (bits)
Link Control Field (LCF) 72
Network Access Code (NAC) 12
Low Speed Data(LSD) 96
Status Symbol 2
The LCF information is further decomposed to
allow entry of specific LCF data units. Encoding of
the following LCFs is supported from the user
interface:
Link Control Opcode Identifier
Value
(binary)
Group Voice Chan User %000000
Unit to Unit Voice Chan User %000011
Adaptive Power Control %001111
271
