Harmonic ProView 2900 - Rate Range; Input Stream Identifier (ISI); ASI Mode

Chapter 7: Stream Configuration Menu Stream Input
© Harmonic Inc. Manual p/n 101543/Ver 1.0 7-7 ProView 2900 Series/SW Version 1.94
7.2.3. Rate Range
The Rate Range parameter defines the range of the ASI input rates.
Rate Range
Rate Range Rate Range
Rate Range
1
11
1

 UPTO 72Mb/s
UPTO 72Mb/s UPTO 72Mb/s
UPTO 72Mb/s
2
22
2

 UPTO 108Mb/s
UPTO 108Mb/s UPTO 108Mb/s
UPTO 108Mb/s
3
33
3

 ABOVE 108Mb/s
ABOVE 108Mb/s ABOVE 108Mb/s
ABOVE 108Mb/s
The available options are:
• UPTO 72Mb/s – Selected when using a CAM for descrambling
• UPTO 108Mb/s – Selected when not using CAM and inputting a transport Stream within
a rate of 72 to 108Mb/s.
• ABOVE 108Mb/s – Not in use.
NOTE
The ASI Input-Rate Range parameter in the front panel interface corresponds with Stream
Rate Range in the Web management interface (see Figure 7-2).
7.2.4. Input Stream Identifier (ISI)
The ProView 2900 support Multiple Input transport Streams (MIS). This support is being done
using DVB-S2 Input Stream Identifier (ISI).
This identifier is present in the Baseband Header of a DVB-S2 Baseband Frame.
The ISI is a single byte identifying the encapsulated stream in case of Multiple Input Streams
and by entering it the user can choose which TS to receive.
Identifier (ISI)
Identifier (ISI)Identifier (ISI)
Identifier (ISI)
00[
00[00[
00[Hex
HexHex
Hex]
]]
]
<
<<
<00
0000
00-
--
-FF
FFFF
FF>
>>
>
The Identifer ISI value ranges from 00[Hex] to FF[Hex].
7.2.5. ASI Mode
The ASI Mode parameter allows selecting between BURST format and NORMAL format.
Type
Type Type
Type
1
11
1

 BURST
BURSTBURST
BURST
2
22
2

 NORMAL
NORMAL NORMAL
NORMAL
