Chapter 2: Introduction Operating Environment
© Harmonic Inc. Manual p/n 101543/Ver 1.0 2-3 ProView 2900 Series/SW Version 1.94
• Telnet - The ProView 2900 supports remote control throughout the Internet. The
ProView 2900 can be controlled and configured from a standard PC terminal (over
Ethernet).
2.1.4. Functionality
The TS Router block receives input streams from an available source, for example: L-Band,
MPEG-over-IP IN and ASI IN. Then the block routes the selected input to the Master and
Slave decoders. Each decoder decodes one program from the input stream, routed by the TS
router block, and provides decoded digital audio and video streams. These streams are
provided to the Video Router block that routes them to the relevant outputs as well as to the
analog video output. The Analog Video Output receives a digital video, converts the digital
video into analog video, and outputs the analog video. The analog and digital audio output
component outputs the digital and analog audio.
Figure 2-1: Signal Path in the ProView 2900 – Functionality Block Diagram
