Chapter 6
Receiver Configuration
This chapter details the Receiver configuration functions provided to the ProView 2900 User.
6.1. ProView 2900 Receiver Configuration Menu Tree
The purpose of the receiver module is to single out a selected Transport Stream from the
transmission that reaches the ProView 2900 inputs, to demodulate it, and pass on the digital
transport stream to the decoder module.
Different networks require various receiver types. According to its licensing, the
ProView 2900 supports the following types of receivers:
1. Satellite Receiver Modules:
• DVB-S Receiver Module The configuration parameters of the DVB-S receiver
module are detailed in Section 6.2.1.
• DVB-S2 Receiver Module The configuration parameters of the DVB-S2
receiver module are detailed in Section 6.2.2.
• DSNG Receiver Module The configuration parameters of the DSNG receiver
module are detailed in Section 6.2.3.
2. IP Receiver Module - The configuration parameters of the IP receiver module are
detailed in Section 6.3.
3. ATM Receiver Module - The configuration parameters of the ATM receiver
module are detailed in Section 6.4.
To access the Receiver Configuration menu using the front panel, select
Configuration

Receiver in the Front Panel menu tree or the Receiver option in the Web
Manager main menu (independently of the receiver module type).
6.2. Satellite Receiver Configuration
This section details the ProView 2900 Front Panel and Web Manager menus that enable
configuring the Satellite Receiver in a ProView 2900 Satellite Front End device.The
ProView 2900 supports three Sattelite Front-End Receiver modules; DVB-S, DVB-S2 and
DSNG.
Figure 6-1 illustrates the structure of the configuration tree menu for the Satellite Receivers.
