Harmonic ProView 2900 - Protocol; IP Address; Subnet Mask; Default Gateway

Chapter 12: GenLock Configuration Menu IP-Out-Port Configuration Menu
© Harmonic Inc. Manual p/n 101543/Ver 1.0 11-7 ProView 2900 Series/SW Version 1.94
11.3.2. Protocol
The Protocol screen displays the currently active L3 protocol and allows setting the protocol
using the following Select Value screen.
Protocol
Protocol Protocol
Protocol
1
11
1

 UDP
UDP UDP
UDP
2
22
2

 RTP
RTP RTP
RTP
The available options are:
• UDP – User Datagram Protocol
• RTP – Real Time Protocol (this feature will be supported in future software releases)
11.3.3. IP Address
The IP Address parameter allows setting the IP Address of the output port.
IP Address
IP Address IP Address
IP Address
010.008.000.216
010.008.000.216010.008.000.216
010.008.000.216
The value in each field must be a whole number between 0 and 255.
11.3.4. Subnet Mask
The Subnet Mask parameter defines the network sub-mask.
Subnet Mask
Subnet Mask Subnet Mask
Subnet Mask
255.255.255.000
255.255.255.000255.255.255.000
255.255.255.000
The value in each field must be a whole number between 0 and 255.
11.3.5. Default Gateway
The Default Gateway parameter allows setting the network default gateway address. This is
the address of a local IP router on the same network as the ProView 2900 that is used to
forward traffic beyond the local network.
Default Gateway
Default Gateway Default Gateway
Default Gateway
010.008.000.001
010.008.000.001010.008.000.001
010.008.000.001
The value in each field must be a whole number between 0 and 255.
