Chapter 12: GenLock Configuration Menu Low Speed Data Port
© Harmonic Inc. Manual p/n 101543/Ver 1.0 11-2 ProView 2900 Series/SW Version 1.94
To access the Data Configuration Menu in the front panel control interface go to
Configuration 

 Data.
All the ProView 2900 models except ProView 2960 and ProView 2990 support the IP Out-
Port option. Following is the corresponding front-panel screen:
Data
Data Data
Data 1
11
1-
--
-2
22
2-
--
-6
6 6
6
1 Low Speed Data Port
1 Low Speed Data Port1 Low Speed Data Port
1 Low Speed Data Port
2 IP Out Port
2 IP Out Port2 IP Out Port
2 IP Out Port
The ProView 2960 and ProView 2990 models support the High Speed Data Port option (and
not IP Out-Port). Following is the corresponding front-panel screen for these models:
Data
Data Data
Data 1
11
1-
--
-2
22
2-
--
-6
6 6
6
1 Low Speed Data Port
1 Low Speed Data Port1 Low Speed Data Port
1 Low Speed Data Port
2 High Speed Data Port
2 High Speed Data Port2 High Speed Data Port
2 High Speed Data Port
The Data Configuration Menu parameters are:
• Low Speed Data Port
Sets the type of data to be outputted through the Low Speed Data port. The
ProView 2900 supports LS data output in three levels of filtering. For details see Section
11.2.
• IP Out Port
Sets the ProView 2900 IP Out port parameters (e.g. the chosen transfer protocol, the
ProView 2900 IP address, UDP port and so on.). For detailed information, see Section
11.3.
• High Speed Data Port (ProView 2960 and ProView 2990 only)
Sets the transfer rate & direction, and the type of data to be sent, through the High Speed
Data port. For details see Section 11.4.
11.2. Low Speed Data Port
This menu is used for setting the ProView 2900 Low Speed Data port parameters.
The ProView 2900 supports Low Speed Data output through RS232. It enables different rates
of transmission, as well as three levels of output-data filtering.
NOTE
The ProView 2900 automatically directs PIDs with the MPEG-2 descriptor -
private_data_indicator = 15 with indicator value 0 for transmission through its Low Speed
Data port.
The minimum amount of data that can be transmitted through the LS Data port is the size of
one PES payload.
To access the Low Speed Data menu in the ProView 2900 front panel control interface go to
Configuration

Data

Low Speed Data Port:
The following screen displays the Low Speed Out Port menu:
