The available transmission rates are: 1200, 2400, 4800, 9600, 19200, 38400, 57600, and
115200 Baud.
NOTE
The LS Data transmission Baud Rate settings must comply with the corresponding encoder
data-encapsulation rate.
11.2.2. Layer Filtering
The ProView 2900 supports three levels of Low Speed Data filtering, determining the type of
data to be transmitted through the LS Data port. Following is the front panel Layer Filtering
screen:
Layer Filtering
Layer Filtering Layer Filtering
Layer Filtering
1
11
1

 DVB STREAMING
DVB STREAMING DVB STREAMING
DVB STREAMING
2
22
2

 PES PAYLOAD
PES PAYLOAD PES PAYLOAD
PES PAYLOAD
3
33
3

 T.S PAYLOAD
T.S PAYLOAD T.S PAYLOAD
T.S PAYLOAD
The three levels of data filtering are:
• DVB STREAMING – For outputting only DVB Asynchronous Data Streaming according
to the EN-301-192 standard (the first 3 bytes of the PES_data_packet are stripped)
• PES PAYLOAD – For outputting only the PES payload (the PES header is stripped)
• T.S PAYLOAD or outputting only the transport stream payload (the TS header and the
adaptation field are stripped)
11.3. IP-Out-Port Configuration Menu
NOTE
When selecting MPE mode, verify that the MPE encapsulator setup is such that the MPEG
packet contains data of a single IP frame (for example, a single MPEG packet cannot contain
data belonging to two separate IP frames).
This menu is used for setting the IP-Out port parameters. To access the IP-Out-Port Menu in
the front panel control interface go to Configuration 

 Data 

 IP Out Port.
The following screen displays the IP Out Port menu:
IP Out Port
IP Out Port IP Out Port
IP Out Port 1
11
1-
--
-2
22
2-
--
-6
66
6-
--
-2
2 2
2
1 Operational Mode
1 Operational Mode1 Operational Mode
1 Operational Mode MPEGoIP
MPEGoIPMPEGoIP
MPEGoIP
2 Protocol
2 Protocol2 Protocol
2 Protocol UDP
UDPUDP
UDP
3 IP Address
3 IP Address3 IP Address
3 IP Address 010.008.000.216
010.008.000.216010.008.000.216
010.008.000.216
4 Network
4 Network 4 Network
4 Network Mask
MaskMask
Mask 255.255.255.000
255.255.255.000255.255.255.000
255.255.255.000
