Chapter 3: ProView 2900 Control Interfaces Initialization and Configuration
© Harmonic Inc. Manual p/n 101543/Ver 1.0 3-10 ProView 2900 Series/SW Version 1.94
3.4. Initialization and Configuration
Before powering-up the ProView 2900, ensure that all cabling is correctly connected. Ensure
that the unit is connected to the main power supply and correctly grounded.
3.4.1. Powering Up
When powering up the ProView 2900 and the receiver is not tuned, expect one of the
following warnings:
• Front-End warning – Demodulator not sync
• Bit Stream warning – No sync – 0x47 detected
• Bit Stream warning – PSI not detected
In case the ProView 2900 warning LED is lit orange, the operator must perform the following:
• Tune or configure the ProView 2900 device
• Select a service from the input stream
When the ProView 2900 is correctly configured, “All OK” is displayed and both LEDs are lit
green.
NOTE
Prior to initialization, review Chapter 5-Operation and Management, for how to use and
navigate through the menus and for information on configuration parameters.
3.4.2. Tuning
The ProView 2900 receiver must be configured to receive a transport stream. For details
about a ProView 2900 device with a DVB-S receiver module, see Section 6.2. For details
about a ProView 2900 device with an MPEG-over-IP front-end module, see Section 6.2.3.10.
3.4.3. Serviceability Check
After installing, initializing, or configuring the ProView 2900, maintenance checks must be
performed to ensure that the unit is serviceable. A video monitor must be connected to the
ProView 2900 to perform the check lists systematic instructions for performing a serviceability
check.
1 On the LCD display, the LCD status message reads "STATUS OK".
2 On the ProView 2900 front panel the two LEDs are lit green.
3 The service selected is displayed on the LCD display.
4 Video picture is displayed on monitor.
5 Audio channels left and right.
