Chapter 7: Stream Configuration Menu Stream Filtering Configuration
© Harmonic Inc. Manual p/n 101543/Ver 1.0 7-17 ProView 2900 Series/SW Version 1.94
NOTE
PID menu is applicable only when service filtering is selected from the Strategy menu.
7.5.5.2. Select PIDs Using the Web Interface
Select PIDs is the corresponding web-management screen that allows the user to select PIDs
in the filtering mode. Figure 7-6 displays the corresponding Select PIDs configuration (Web
Management screen).
Figure 7-6: Select PIDs Menu Screen
Select PIDs screen includes following parameters:
• Const PIDs - This parameter lists all available SI PID's and allows the user to select SI
PIDs. In order to select SI PIDs, select the PIDs check boxes and click Submit.
• Referenced PIDs - This parameter lists all available services PIDs on the received
transport-stream grouped under the relevant Service' nametag. It allows selection of
specific PIDs. In order to select a PID to filter, select the needed PIDs' check boxes and
click Submit.
• Unreferenced PIDs - This parameter lists all selected unreferenced PIDs. it allows
removal of an unreferenced PIDs. In order to remove an unreferenced PID, select the
PID' check box and click Submit.
NOTE
Unreferenced Services is unavailable when no unreferenced services have been selected.
• Manual PID - This parameter allows the user to manually add PIDs by entering the PIDs
symbol in the text box and click on Submit.
NOTE
When the manually selected PID is a constant SI PID or it is part of a referenced service, the
relevant checkbox is checked; otherwise, the manually selected PID is added under the
unreferenced PIDs list
• Clear - Clicking on Clear button empty all selected fields.
NOTE
Service menu is applicable only when service filtering is selected from Strategy menu
