Chapter 2: Introduction Mechanical Structure
© Harmonic Inc. Manual p/n 101543/Ver 1.0 2-13 ProView 2900 Series/SW Version 1.94
The MPEGoIP input interface can be supported by all ProView 2900 devices.
Figure 2-13 illustrates the ProView 2961 rear panel with an MPEGoIP input interface.
Figure 2-14 illustrates the ProView 2961 rear panel with DVB-S (QPSK) Dual Input
configuration.
Figure 2-15 displays the ProView 2961 rear panel with Decoder Only configuration.
Figure 2-13: ProView 2961 Rear Panel (IP Input interface)
Figure 2-14: ProView 2961 Rear Panel (DVB-S Dual Input interface)
Figure 2-15: ProView 2961 Rear Panel (Decoder Only interface)
NOTE
ProView 2900 models supporting MPEGoIP output and IP data out (MPE de-capsulation)
output can be configured to support either MPEGoIP or IP data out.
