Arm status

H000002007-RDS User Manual │Version 5.0.0 (2018-09-17) │114

H. ARM STATUS

Click on the Arm status tile: this screen shows information about the selected arm.

The Arm Status can be used both for the currently connected arm and for an Off-line arm

The displayed information is grouped by categories:
