RDS Control Panel
H000002007-RDS User Manual │Version 5.0.0 (2018-09-17) │68
Default scanning profiles
RS2-5
HP-L-8.9
CMS108
HP-L-20.8
LAS
LAS-XL
Alignment
Sphere
Plane
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
This profile is designed for the scanner Alignment and is
automatically used during this process. At the end of the
Alignment, the profile returns to the originally selected one.
Standard
✓
✓
Default profile for RS5 (Linear) RS2,3,4 (static exposure) and HP-
L-8.9 (manual exposure)
Edge
✓
✓
✓
Profile for small details: highest resolution, but narrowest line.
Feature
✓
✓
✓
✓
Standard profile, mid-size part and some details.
Surface
✓
✓
✓
✓
Profile for large parts with a few details.
Line width (mm)
Points spacing (mm)
Sampling
Gain
Quality
filter
CMS
108
HP-L-
20.8
LAS
LAS-
XL
CMS
108
HP-L-
20.8
LAS
LAS-
XL
Points
Line
Edge
25
51
51
-
0.050
0.050
0.013
-
100 %
100%
Normal
On
Feature
60
63
63
228
0.060
0.025
0.013
0.226
100 %
100%
Normal
On
Surface
120
220
220
468
0.120
0.055
0.050
0.905
100 %
100%
Normal
On
