LANtools network management
212
5.7 LANmonitor—know what's going on
BAT54-Rail/F..
Release 7.54 06/08
On the 'Protocol' tab you can define whether the following activities
should be protocolled:
D WAN connections
D WLAN connections
D VPN connections
D LANCAPI connections
D a/b port connections
D Firewall actions
You can also specify whether LANmonitor should create a log file daily,
monthly, or on an ongoing basis.
5.7.4 Tracing with LANmonitor
Traces can be executed very easily with LANmonitor. Simply click on the en-
try for the device with the right-hand mouse key and select Traces from the
context menu.
