Appendix
524
13.3
Radio channels
BAT54-Rail/F..
Release
7.54
06/08
13.3Radio channels
13.3.1 Radio channels in the 2,4 GHz frequency
band
In the frequency range from 2400 to 2483 MHz are up to 13 channels avail-
able. The following overview shows which channels are supported by the dif-
ferent regions (EU/WORLD). The last column shows which channels can be
used without overlapping.
13.3.2 Radio channels in the 5 GHz frequency band
In the frequency range from 5,13 to 5,805 GHz up to 19 non-overlapping
channels are available in Europe, defined as the sub-bands as follows:
Disassociated WLAN sta-
tion due to station request
Access point WLAN station was signed off due to a request from the sta-
tion
Rejected association from
WLAN station
Access point The sign on of the WLAN station was rejected
WLAN card hung, reset-
ting
Access point or
client
WLAN card stopped, reset
Frequency range 2400–2500 MHz no overlapping with
Channel No. EU (ETSI) WORLD (ETSI + FCC)
1 2412 2412 6, 11
2 2417 2417 7
3 2422 2422 8
4 2427 2427 9
5 2432 2432 10
6 2437 2437 1, 11
7 2442 2442 2
8 2447 2447 3
9 2452 2452 4
10 2457 2457 5
11 2462 2462 1, 6
12 2467 – –
13 2472 – –
Bold values indicate the default setting of the BAT radio adapters when utilized in a base station.
WLAN traps Operating mode Explanation
