Routing and WAN connections
BAT54-Rail/F..
Release
7.54
06/08
11.7
Changes in other services
413
D Default: Any
Note: Binding to all logical interfaces with the setting 'any' is only possible for
devices with a LAN bridge.
D VLAN ID
ID of the VLAN with the active IPX router.
D Default: 0
11.7.11Assigning logical interfaces to bridge
groups
Particular properties of the logical interfaces are defined in the port table.
D Active
This option activates or deactivates the logical interface.
D Bridge group
Assigns the logical interface to a bridge group to enable bridging from/to
this logical interface via the LAN bridge. If assigned to a common bridge
group, several logical interfaces can be addressed at once and they
appear to the BAT Router to be a single interface. This can then be used
for Advanced Routing and Forwarding, for example.
D Values: BRG-1 to BRG-8, none
D Default: BRG-1
D Special significance: If the interface is removed from all bridge groups
by setting 'none', then there is no communication between the LAN
and WLAN via the LAN bridge (isolated mode). With this setting, LAN/
WLAN data transfers over this interface are only possible via the
router.
Configuration tool Call
LANconfig Interfaces
 Spanning Tree
WEBconfig, Telnet Expert Configuration > Setup > LAN Bridge > Port Data
