HP 3600 v2 Series User Manual

217
Field Descri
p
tion
BGP last state Previous state of the peer.
Port TCP port numbers.
Configured: Active Hold Time: 180 sec
Keepalive Time: 60 sec
Local holdtime interval and keepalive interval.
Received: Active Hold Time Remote holdtime interval.
Negotiated: Active Hold Time Keepalive
Time:60 sec
Negotiated holdtime interval and keepalive interval.
Peer optional capabilities
Optional capabilities that the peer supports, including
multiprotocol BGP extensions and route refresh.
Peer support bgp multi-protocol extended The peer supports multiprotocol BGP extensions.
Peer support bgp route refresh capability The peer supports route refresh.
Peer support bgp route AS4 capability The peer supports 4-byte router IDs.
Address family IPv4 Unicast Routes are advertised and received in IPv4 unicasts.
Received Total numbers of received packets and updates.
Sent Total numbers of sent packets and updates.
Maximum allowed prefix number Maximum allowed prefix number.
Threshold Threshold value.
Minimum time between advertisement runs Minimum route advertisement interval.
Optional capabilities
Optional capabilities that the peer enables (displayed only
after optional capabilities are configured).
Route refresh capability has been enabled The route-refresh capability has been enabled.
ORF advertise capability based on prefix (type
64):
The BGP peer supports the ORF capability based on IP
prefix. The capability value is 64. (This field is displayed
only after the ORF capability is enabled for the BGP peer.)
Local: both
The local BGP router supports both the ORF sending and
receiving capabilities. (This field is displayed only after the
ORF capability is enabled for the BGP peer.)
Negotiated: send
Negotiation result: The local BGP router can send
route-refresh messages that carry the ORF information, and
the peer can receive route-refresh messages that carry the
ORF information.
• If receive is displayed, the local BGP router can receive
route-refresh messages that carry the ORF information,
and the peer can send route-refresh messages that carry
the ORF information.
• If both send and receive are displayed, the local BGP
router and the peer can both send and receive
route-refresh messages that carry the ORF information
• This field is not displayed if neither the send nor the
receive capability is supported.
• This field is displayed only after the ORF capability is
enabled for the BGP peer.
Peer Preferred Value Preferred value specified for the routes from the peer.
