HP 3600 v2 Series User Manual

62
<Sysname> mtracert 6.6.6.6 5.5.5.8 225.2.1.1
Type Ctrl+C to quit mtrace facility
Tracing reverse path of (6.6.6.6, 225.2.1.1) from last-hop router (5.5.5.8) to source
via multicast routing-table
-1 5.5.5.8
Incoming interface address: 4.4.4.8
Previous-hop router address: 4.4.4.7
Input packet count on incoming interface: 17837
Output packet count on outgoing interface: 0
Total number of packets for this source-group pair: 8000
Protocol: PIM
Forwarding TTL: 0
Forwarding code: No error
-2 4.4.4.7
Incoming interface address: 6.6.6.7
Previous-hop router address: 0.0.0.0
Input packet count on incoming interface: 2
Output packet count on outgoing interface: 259
Total number of packets for this source-group pair: 8100
Protocol: PIM
Forwarding TTL: 0
Forwarding code: No error
Table 16 Command output
Field Descri
p
tion
(6.6.6.6, 225.2.1.1) (S, G) multicast stream for which the forwarding path is being traced
-1 5.5.5.8
(S, G) outgoing interface address of each hop, starting from the last-hop
router
Incoming interface address IP address of the interface that received the (S, G) packets
Previous-hop router address
IP address of the previous router that forwards the packets to the current
router
Input packet count on incoming
interface
Total number of multicast packets that the incoming interface received
Output packet count on
outgoing interface
Total number of multicast packets that the outgoing interface transmitted
Total number of packets for this
source-group pair
Total number of packets from the specified source that this router forwards to
the specified group
Protocol Multicast routing protocol in use
Forwarding TTL
Minimum TTL that a packet must have before it can be forwarded over the
outgoing interface
