Making Measurements
Measuring Impedance Using the Smith Chart
I
I
P
0
Figure 3-24. Determining the Magnitude and Phase of the Reflection Coefficient
4. Figure 3-25 on the next page, shows an example of an actual
measurement. Note the marker readout in the upper right corner of the
display. The marker values are frequency, resistance, reactance, and the
equivalent capacitance or inductance, respectively.
