Calibrating for Increased Measurement

Accuracy

Check the Calibration

Directivity

Directivity is a reflection measurement error term.

Corrected directivity less than -40

is expected after

calibrations have been performed. This is the same value

YOU

would measure when measuring a load standard.

di3

tl:

Memory

D2:

off

Log

Mag

10.0

dB/

Ref

-70.00

-110

I I I I

1 I

Start

0.300

MHZ

Stan

300.000

MHZ

Figure 6-4. Typical Directivity Error Term
