I
-
(-1
/
SQftkqr
Reference
C
C
Cable
ICAL)
Cal,
mieck
Cal
Kit
Cal
on
OFF
(O~Zion
100
only)
Softkey
in
(BEGIN)
menu. Used to perform fault location
and SRL measurements. See your Option 100 User’s Guide Supplement for
information.
Hardkey in the CONFIGURE area. Displays the calibration menu options for
the current measurement mode.
See Chapter 6 for information on calibrating the analyzer.
Softkey
in
a
menu. Provides access to the cal check menu. The cal
check feature will compute and display corrected measurement uncertainties
(residual errors) that apply to the current instrument settings and
calibrations. This information may be used as an analysis or troubleshooting
tool when making transmission and reflection measurements.
See Chapter 6 for more information on using cal check.
Softkey
in (CAL) menu. Allows selection of type of cal kit: Type-N female
(default), Type-N male, 3.5 mm (for use with 50
fl
systems), Type-F female
(for use with 75
fl
systems), or user-defied.
By convention, cal kits indicate the sex of the
pot%
with which they are used.
For example the default cal kit for the analyzer is type-N
female
because the
front panel RF ports are female (the calibration standards, in turn, are male).
This same convention applies to whatever test “port” the standard is attached
to, be it an adapter, cable, fixture, etc.
See Chapter 6 for more information on calibrating the analyzer.
Softkey
in
deEne
save menu.
‘Joggle
to ON if you want to save the active
measurement calibration along with the current instrument state.
See “Saving and Recalling Measurement Results” in Chapter 4 for information
on saving instrument states and measurement results to files.
Access Keys: (SAVE RECALL)
Def
We Save
9-13
