I
-
Ext
Bef
Softkey
in source (MENU). When on, sets network analyzer to use external
on
QFF
10 MHz signal as frequency standard. When on, if signal is not present at
EXT REF
lN
connector, network analyzer will not sweep. Default is off.
NOTE
External reference should be disconnected from EXT
REF
IN or power reduced when not in use.
Extern&.
Softkey
in trigger source menu. Enables the analyzer to sweep to the next
POiRti
(frequency) point when externally triggered through EXT TRIG IN/OUT rear
panel connector, one point per trigger.
9-26
&t@raal
Softkey
in trigger source menu. Enables the analyzer to begin one complete
Swaep
sweep when externally triggered.
Access Keys:
(jj]
Trigger
Trigger
Source
