Specifications and Characteristics
General Characteristics
limit Test Output
This connector outputs a TTL signal of the limit test results. Pass: TTL high;
Fail: TTL low.
Video Output Color VGA
This connector provides signals to drive an external VGA compatible monitor.
See
Table
8-2 for more information.
Vertical rate: 59.82 Hz
Horizontal rate: 31.41
kHz
(31.84 ps)
Pixel rate: 25 MHz
HP-IB
Parallel Port
M-232
LAN
DIN Keyboard
line Power
This connector allows communication with compatible devices including
external controllers, printers, plotters, disk drives, and power meters.
This
25-pin
female connector is used with parallel (or Centronics interface)
peripherals such as printers and plotters. It can also be used as a general
purpose I/O port, with control provided by
IBASIC
and SCPI commands.
This
g-pin
male connector is used with serial peripherals such as printers and
plotters.
This
RJ-45,
“ether-twist,” connector is used for connecting the analyzer to a
LAN. This connector is functional only with Option
lF7.
See the Option lF7
User’s Guide supplement for more information on using this connector.
This connector is used for connecting and using an IBM PC-AT compatible
keyboard for title entry, remote front-panel operation, and for
IBASIC
programming (Option
lC2).
47
to 66 Hz
115 V nominal (90 V to 132
V)
or 230 V nominal (198 V to 254
V).
300 VA max
User TTL Input/Output
This connector provides a bidirectional open collector TTL signal that can be
accessed by
IBASIC
and SCPI commands. It also can be used as a sweep out
connector, and as a softkey-auto step connector (with an external switch).
lo-18
