Preset State and Memory Allocation
SOURCE Key Settings (continued)
Power level
RF power
Power sweep start power
Power sweep stop power
Trigger source
Trigger mode
Number of points
Start distance*
Stop distance*
External reference
Sour avoid options
preset power level1
On
0.0 dBm
1.0 dBm
Internal
Continuous
201
0.00 ft IO.00 ml
100.00 ft 130.48 ml
Off
None
1 Preset power level is user-defined by using the Preset Pwr Level key The factory default is 0 dBm.
2 Aoalpers with Option 100 only
CONFIGURE Key Settings
I
(SCALE)
I
Scale/div
10 dB/div
Reference level
0 dB
Reference position
5
Reference tracking
Off
Electrical delay
OS
Phase offset
0 degrees
