Making Measurements
Making a Power Measurement using Broadband Detection
)I: Power )I: Power
D2: Off D2: Off
Log MagLog Mag
0.5 dB/ Ref0.5 dB/ Ref
5.00 dBm 5.00 dBm
3
AbsAbs
Start 10.000 MHz
Stop 1 300.000 MHz
Figure 3-l 2. Example of a Power Measurement
Start 10.000 MHz
Stop 1 300.000 MHz
Figure 3-l 2. Example of a Power Measurement
3-34
CAUTION
If the analyzer’s RF output power level is set to higher than the specified
output power for your analyzer, the source could go unleveled. See
Chapter 10 for source and receiver specifications. If your device requires
input power greater than your analyzer’s specified output power, you may
need to use a preamplifier in your measurement setup. However, remember
to not exceed the receiver damage limit of +23 dRm.
