Table 3 PCI/PCI-X/PCIe I/O Rope Groups (continued)
Hot
Swap/OLRFunctionSpeedBits
Logical Rope
Numbers
Physical Rope
NumbersSlot #
YHigh-Speed PCI-X
(Public)
133 MHz6422, 37
YHigh-Speed PCI-X
(Public)
133 MHz64598
YGeneral PCI-X (Public)66 MHz64119, 10
NUCIO (Private)33 MHz3200-
PCIe MPS Optimization
For PCIe-based systems, each PCIe device has a configurable MPS (maximum payload size)
parameter. Larger MPS values can enable the optimization to gain higher performance. MPS
Optimization is supported on PCIe systems running HP-UX, OpenVMS, and Linux. System firmware
level greater than 02.03 performs an optimization during boot time to set the MPS value to the
largest size supported by both a PCIe root port and the devices below it.
The default server state is optimization disabled. When disabled system firmware sets MPS to the
minimum value on each PCIe device.
The info io command will display the current PCIe MPS optimization setting. See “info” (page 321).
To enable PCIe MPS optimization, use the ioconfig mps_optimize command. See “ioconfig”
(page 319).
For non-PCIe systems, ioconfig and info io will not display the MPS optimization policy
setting. The Set PCIe MPS Optimization boot manager menu also will not be displayed. Running
the ioconfig mps_optimize [on|off] command from a non-PCIe system, the following
output will be displayed:
-------------
Shell> ioconfig mps_optimize
ioconfig: PCIe MPS optimization is not supported.
Shell> ioconfig mps_optimize on
ioconfig: PCIe MPS optimization is not supported.
Exit status code: Unsupported
Shell>
-----------------
To restore MPS to the default values, use the default clear command. See “default” (page 320).
Processor
The server processor subsystem accommodates one, two, three, or four dual-core Itanium processor
modules. The processor subsystem consists of the following components:
• zx2 CEC front side bus, memory, and I/O controller
• System clock generation and distribution
• Circuitry for manageability and fault detection
The zx2 CEC and the processor modules are located on the processor board assembly. Each
processor connects to the processor board through a zero insertion force (ZIF) socket. The processor
board is mounted on a removable carrier tray that is attached to the processor board access door.
Access this assembly from the front of the server after the memory carrier is removed.
20 Overview
