c. Reinstall the disk drive.
d. Restart the HP server to determine whether the LED now becomes illuminated during the
boot. If not, contact your reseller.
5. To check the SCSI drives, use the EFI Shell info io command.
LAN LEDs
There are LAN LEDs on the rear bulkhead of LAN HBA in PCI-X slot 2 with 1 core I/O SAS card
installed.
HBA Bulkhead LAN LEDs
There are two 1 Gb LAN ports on the LAN HBA’s bulkhead. They are LAN A and LAN B.
LAN A Connector LEDs
The 1 Gb LAN A interface provides two LEDs on the LAN bulkhead.
Table 65 lists the Gb LAN A connector LEDs.
Table 65 LAN A Connector LEDs
StateColorLocationLAN LED
NoneNoneTopNot used
The 1000 Mb/s ethernet protocol and twisted-pair wiring is
enabled.
Blinking
amber
2nd from top1000Mb
No linkOff
The 100 Mb/s with ethernet protocol and twisted-pair wiring is
enabled.
Blinking
green
2nd from bottom100Mb
No linkOff
The activity LED is enabled.Blinking
green
BottomActivity
No activityOff
LAN B Connector LEDs
The 1 Gb LAN B interface provides two LEDs on the LAN bulkhead.
Table 66 lists the Gb LAN B connector LEDs.
Table 66 LAN B Connector LEDs
DescriptionColorLocationLED
The 1000 MHz with ethernet protocol and twisted-pair wiring
is enabled.
YellowUpper leftSpeed (upper
left)
The 100 MHz with ethernet protocol and twisted-pair wiring
is enabled.
Green
No linkOff
link is enabled.GreenUpper rightLink (upper
right)
No linkOff
Booting
Table 67 shows the normal boot process, as reflected in changes to front panel LED states:
Booting 169
