Table 54 lists the memory subsystem evens that may light the diagnostic panel LEDs.
Table 54 Memory Subsystem Events That May Light Diagnostic Panel LEDs
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
SFWUnable to clear the
platform error logs in
CEC
Type E0h, 189d:26d
MEM_ERR_LOG_FAILED_TO_CLEAR
Processor
Carrier
SFWSelf-test of CEC
multi-bit error
signaling has failed
Type E0h, 181d:26d
MEM_ECC_MBE_SIGNAL_TST_FAILED
Processor
Carrier
SFWThe CEC failed the
register test
Type E0h, 160d:26d MEM_BIB_REG_FAILUREProcessor
Carrier
SFWSystem firmware
(SFW) was unable to
Type E0h, 187d:26d
MEM_ECC_MBE_SIGNAL_TST_FAILED
Processor
Carrier
clear the platform
error logs on the CEC
SFWThe error registers in
the CEC failed to clear
Type E0h, 190d:26d
MEM_ERR_REG_CLEAR_FAILURE
Processor
Carrier
SFWThe CEC’s memory
controller failed the
register test
Type E0h, 208d:26d MEM_MC_REG_FAILUREProcessor
Carrier
Voltage wholly
contained on
BMCExpander voltage
error
Type 02h, 02h:07h:06h
VOLTAGE_NON_RECOVERABLE
Memory
Carriers
memory
expander
shows failure
The failing
DIMM’s rank
SFWDetected that an
SDRAM is failing on
the DIMM
Type E0h, 4000d:26d
MEM_CHIPSPARE_DEALLOC_RANK
DIMMs
will be
deallocated
SFWDIMM type is not
compatible with
Type E0h, 174d:26d
MEM_DIMM_TYPE_INCOMPATIBLE
DIMMs
current DIMMs for this
platform
SFWDetected a fatal error
in DIMM’s serial
presence detect (SPD)
Type E0h, 173d:26d MEM_DIMM_SPD_FATALDIMMs
24 / 48 slot
version of
memory carrier
SFWDIMM mismatch found
within rank of four
Type E0h, 795d:26d
MEM_DIMM_QUAD_MISMATCH
DIMMs
8 slot version
of memory
carrier
SFWDIMM mismatch found
within rank of two
Type E0h, 779d:26d
MEM_DIMM_PAIR_MISMATCH
DIMMs
Troubleshooting SBA
The server shares a common I/O backplane that supports a total of 10 PCI slots: slots 1-2 on
systems with only one core I/O SAS card, and slots 1, 2, and 10 for systems with two core I/O
SAS cards, are for customer use. Slots 2-10 are used for core I/O functions on systems with only
1 SAS core I/O card; slots 2-9 are used on systems with 2 SAS core I/O cards. The System Bus
Adapter (SBA) logic within the zx2 chip of a server uses 16 rope interfaces to support up to eight
