Table 23 Memory Configuration Requirements
Maximum Memory
Configuration
Minimum Memory
Configuration
Memory Boards InstalledMemory Carrier Type
192 GB (six quads:
24x8-GB DIMMs)
2 GB (one quad: four
512-MB DIMMs)
1 X 24-DIMM memory
board
24-DIMM memory carrier
(configuration 1)
384 GB (12 quads:
48x8-GB DIMMs)
2 GB (one quad: four
512-MB DIMMs)
2 X 24-DIMM memory
boards
48-DIMM memory carrier
(configuration 2)
Memory Load Order
When installing memory, use a minimum of one quad of like-sized DIMMs. Insert additional DIMMs
into the 48-DIMM memory carrier in the next available quad, in order of capacity from largest to
smallest.
Install DIMMs into the appropriate slots on the 48-DIMM memory carrier boards; each slot has a
unique ID. Use Figure 27 to determine where to install DIMMs on the memory carrier board.
CAUTION: Failure to observe these cautions results in system degradation or failure.
• Do not mix DIMM sizes or types within a quad.
• Load DIMM quads in order of size from largest to smallest. For example, if you have a quad
of 2 GB DIMMs and a quad of 1 GB DIMMs, install the quad of 2 GB DIMMs first.
24-DIMM Memory Carrier Load Order
For a single 24-DIMM memory board configuration, load DIMMs in order from quad 0 to quad
5.
48-DIMM Memory Carrier Load Order
The 48-DIMM memory carrier has two sides, labeled side 0 and side 1, each of which can contain
a memory carrier board. The 48-DIMM memory carrier can contain up to 12 quads of memory.
DIMM quads are loaded in order of capacity from largest to smallest.
The DIMM slot IDs are the same for both 24-DIMM memory carrier boards. Unique slots are
identified within the carrier by the side in which they reside. For example, slot 0A is identified as
slot 0A, side 0; or slot 0A, side 1.
Figure 27 shows the DIMM slot IDs for the 48-DIMM memory carrier board.
Installing Additional Components 61
