Table 9 Core I/O Board Ports (continued)
DescriptionPort
Local serial port that provides a console connection to the serverConsole Serial (iLO 2 MP)
Two public USB 2.0 ports used primarily to connect to a keyboard and mouse
for console input functions (Windows and Linux operating systems only)
USB
VGA port used primarily to connect to a monitor that displays console output
(Windows and Linux operating systems only)
VGA (optional)
iLO 2 MP Status and LAN LEDs
Table 10 shows the states and status of the iLO 2 MP status and LAN LEDs.
Table 10 iLO 2 MP Status and LAN LEDs
StatusStatesiLO 2 MP LED
Standby power is onSolid greenStandby power
iLO 2 MP self test running
1
Amber
iLO 2 MP Self test
Self test completedOff
Operational and functionalFlashing greeniLO 2 MP Heartbeat
Operational and functionalFlashing greenBMC Heartbeat
ActivityBlinking green
Link Status Link with no activitySolid green
No linkOff
100 Mb linkSolid amber
Link Speed
10 Mb linkOff
1
The LED is solid amber when AC power is first applied. It remains solid amber for a few seconds until the iLO 2 MP
completes its self test; the LED then turns off.
System LAN
The system LAN functionality is provided by the LAN core I/O card. The ports on the LAN core
I/O card are two RJ-45 style 10 Base-T/100 Base-T/1000 Base-T system LAN ports.
Table 11 show the system LAN link status and speed LEDs states and status.
Table 11 System LAN Link Status and Speed LEDs
Link StatusStateLED
ActivityBlinking green
Link status Link with no activitySolid green
No linkOff
1000 MbSolid orange
Link speed
100 MbSolid green
10 MbOff
36 Overview

HP Integrity rx6600 Specifications

General

Processor	Intel Itanium 2
Network	Integrated dual Gigabit Ethernet
Form Factor	5U rack-mountable
Power Supply	Redundant hot-plug power supplies
Processor Speed	1.6 GHz
Memory Type	DDR2 ECC Registered
RAID Support	Yes
Operating System	HP-UX, Linux, Windows Server
